Feedback mechanisms between shoreline undulations and waves involving both the surf and the shoaling zones. Wave incidence from the left. The blue lines with arrows indicate the wave rays. The brown arrows indicate the larger or smaller total sediment transport rate. A crest (C) is shown along with the two nearest embayments (E).
