Biomonitoring of marine pollution

Biomonitoring uses organisms and their biological responses to detect pollutant exposure and harmful biological effects, including effects of substances or mixtures that may escape chemical monitoring.

The Coastal Wiki articles on this subject provide complementary perspectives:


Effects of diverse toxic substances on different marine animals are described in articles in the category ecotoxicology.


Introduction

A biomarker is a measurable biological characteristic or response that indicates exposure to pollutants or their biological effects. Biomarkers can be measured at molecular, biochemical, cellular, physiological or behavioral level. Some biomarkers respond mainly to particular classes of contaminants, whereas others indicate more general physiological stress or damage. Their interpretation therefore requires information on contaminant exposure and on environmental and biological factors that can also influence the response.

Biomarkers are generally measured in selected bioindicator or sentinel species. Suitable bioindicators are readily sampled, sufficiently abundant and show a well-characterized response to the pollutants or effects being monitored. Mussels and other bivalves are widely used in coastal biomonitoring because they are sessile, filter large volumes of water and accumulate many contaminants over time. Their limited mobility allows observed contaminant burdens and biomarker responses to be related relatively closely to local environmental conditions. Besides monitoring indigenous mussel populations, active biomonitoring can be carried out by transplanting or caging mussels at selected sites, which allows greater control over their origin and exposure period.[1]

Fish provide complementary information. They occupy higher trophic levels, accumulate contaminants through both water and food, and permit assessment of a wide range of biochemical, physiological and pathological effects. In wild fish, however, the location and duration of previous exposure are often uncertain, which makes it difficult to relate biomarker responses to a specific pollution source. Active biomonitoring with caged fish can overcome this limitation by exposing animals of known origin at selected sites for a defined period.[2][3]

Different bioindicator species therefore provide complementary information rather than interchangeable measures of pollution. Modern biomonitoring programmes commonly combine biomarkers from several sentinel species with measurements of contaminant concentrations and relevant environmental conditions.[4]

Biomarkers are commonly classified according to whether they indicate exposure, biological effects or susceptibility to adverse effects. The biomarkers considered in this article mainly belong to the first two groups. Biomarkers of biological effect include indicators of cellular and physiological stress, genotoxicity and reproductive impairment.

Biomarkers of exposure

Biomarker Mainly indicates
metallothioneins [5][6] Exposure/adaptation to certain metals
Mixed-function oxygenase [7][8][9][10] / CYP1A / EROD activity [11] Exposure to AhR-active organic contaminants such as certain PAHs and planar halogenated compounds
Acetylcholinesterase inhibition[12][13] Exposure to neurotoxic compounds that inhibit cholinesterase activity
PAH metabolites in fish bile Recent uptake of PAHs

For example, metallothioneins (MTs) are small proteins present inside cells that bind metal ions. They play an important role in regulating essential metals such as zinc and copper and in detoxifying toxic metals such as cadmium and mercury. Exposure to elevated metal concentrations stimulates the production of metallothioneins, which can therefore be used as biomarkers of metal exposure.

Biomarkers of cellular and physiological stress

Biomarkers related to physiological stress indicate the effects of a wide range of pollutants; they are not substance specific. Cellular and physiological stress include: oxidative stress, lysosomal membrane stability, neutral lipid/lipofuscin accumulation and scope for growth.

Reduced tolerance to environmental stress

Some biomarkers assess whether exposure to pollutants has reduced the capacity of an organism to cope with additional environmental stress. Two examples are the stress-on-stress response and scope for growth.

The stress-on-stress biomarker measures the resistance of an organism to a standardized stress after prior exposure to pollution. In molluscs, this is often tested by exposing the animals to air and recording their survival time. Polluted or physiologically stressed animals generally have less physiological reserve and therefore survive for a shorter period than unstressed reference animals. The test thus indicates whether pollution has diminished the organism's capacity to withstand environmental stress.

Scope for growth estimates the energy available for growth and reproduction after subtracting metabolic costs from the energy acquired through feeding. Pollution can reduce this energetic surplus by impairing feeding or increasing metabolic costs.

Histological and cytological stress parameters

Fig. 1 Dilated extracellular spaces between adjacent ciliated cells in the palps of the mussel Mytilus galloprovincialis. Such morphologigal alterations are often related to the effects of pollutants.
Fig. 2 Lipid inclusions in digestive tubule cells of the mussel Mytilus galloprovincialis stained with Oil Red O. The size and the number of these cell compounds are often affected by pollution.
Fig. 3 Cryosection of a digestive gland tubule of the mussel Mytilus galloprovinciali. The lysosomes in the tubule cells are stained purple with the enzyme N-acetyl-β-hexosaminidase for the assessment of lysosomal membrane stability[14][15][16]. Similar cryosections are used for the application of the biomarker LMS, as well as for cytological / morphometrical observations.

Histopathological biomarkers detect structural changes in cells, tissues and organs. Because they represent actual tissue damage, they are generally more directly relevant to organism health than early molecular responses, but are less specific to particular pollutants.

Pollution can alter the structure and functioning of cells before effects become visible at the level of the whole organism. In mussels, the digestive gland is often examined because it is an important site of contaminant uptake, storage and detoxification.[17][18]

Histological and cytological biomarkers include changes in cell and tissue structure, accumulation of neutral lipids and lipofuscin, and changes in lysosomal membrane stability. Figures 1 and 2 illustrate structural and intracellular changes that can occur in mussels exposed to pollutants: Fig. 1 shows altered spacing between epithelial cells, whereas Fig. 2 shows accumulation of lipid inclusions in digestive-gland cells.[19][5]

Lysosomes are cell organelles involved in the breakdown and sequestration of foreign or harmful substances. Their membranes can become destabilized under pollutant stress. Lysosomal membrane stability (LMS) is therefore widely used as a biomarker of cellular stress in mussels. Figure 3 shows a cryosection of a digestive-gland tubule in which lysosomes are stained for LMS assessment.

In the LMS test, the stability of lysosomal membranes is assessed from the time required for acid treatment to release lysosomal enzymes and produce maximum staining. Shorter labilization times indicate lower lysosomal membrane stability and generally greater cellular stress, whereas longer times indicate more stable lysosomes.[20][16]

Biomarkers of genotoxicity

DNA damage

Genotoxicity biomarkers include DNA single- and double-strand breaks, modified bases, DNA-DNA crosslinks and DNA-protein crosslinks. Alkaline elution and the COMET assay are commonly used methods for detecting such damage.[21][22][23] [24][25][26]

Micronucleus formation

The micronucleus(MN) test is a cytogenetic technique commonly used for the evaluation of genotoxic effects caused by chemical stressors. Micronuclei are formed during cell division when whole chromosomes or chromosome fragments fail to be incorporated in the daughter nuclei, forming small additional nuclei. The test consists in the scoring of cells containing one or more cytosolic micronuclei in addition to the main nucleus.[22][27][28] as well as in in different cell types of fishes.[29][30][31]

Biomarkers of reproductive impairment

Pollutants can impair reproduction through several mechanisms, including direct toxicity to reproductive tissues and disruption of hormonal regulation. Substances that alter function(s) of the endocrine system are called Endocrine Disrupting Compounds (EDCs).

Histological parameters for assesment of changes in gonad development are often used in both molluscs and fish studies. Biomarkers assessing gonad (sex gland) development (such as ‘simple gonad index’ or ‘changes in structure of gonad tissue’) are helpful, giving indications of the effects of pollution on the reproductive performance of animals.[32][33][34] [35][36]

Vitellogenin is normally produced in mature female fish under estrogenic stimulation. Its induction in males or juveniles therefore provides a sensitive biomarker of exposure to estrogenic substances. Other biochemical indicators of endocrine disruption which have been regarded as useful tools for an assessment of endocrine disruption caused by chemicals in fish include changes in zona radiata proteins (zona radiata=radiately striated membrane situated next to the yolk of an ovum)[37][38] and steroid hormone balance.[39][40][41]

Endocrine-mediated reproductive effects and their mechanisms are discussed in Endocrine disruption by marine pollutants.

Combining biomarkers

No single biomarker provides a complete assessment of pollution impact. Exposure biomarkers can indicate contact with particular contaminant classes, whereas general stress, genotoxicity, histopathology and reproductive biomarkers provide information on biological effects of increasing ecological relevance but generally decreasing pollutant specificity. Biomonitoring programs therefore commonly combine several complementary biomarkers with measurements of contaminant concentrations.

Interpretation requires standardized methods and suitable reference or assessment values because biomarker responses are also influenced by factors such as temperature, season, age, nutritional condition and reproductive state. Integrated approaches combining chemical and biological-effect measurements are used in marine monitoring programs such as OSPAR's Coordinated Environmental Monitoring Program.[42]

High-throughput molecular approaches such as transcriptomics, proteomics and metabolomics are increasingly used to identify pollutant-response pathways and candidate biomarkers. Their application in routine environmental monitoring remains more limited because standardization, natural variability and interpretation of ecological significance are challenging.
